Tibia Load Cells

The tibias are also equipped with four load cells. Each tibia consists of two load cells, in the upper and the lower tibia. They are listed in the table below. The location of the load cells is depicted in the figure below:

Item	Beam ID	Label	Channels in physical dummy
Upper tibia load cell left	10016	TIBILEUPWS	Six-channel load cell
Upper tibia load cell right	10017	TIBIRIUPWS	Six-channel load cell
Lower tibia load cell left	10018	TIBILELOWS	Six-channel load cell
Lower tibia load cell right	10019	TIBIRILOWS	Six-channel load cell



Tibia load cell beams
